CDM-800 Gateway Router
Installation
Detail Description
1
2
Item
KT/6228‐2
1
2
3
4
5
6
Figure 2-3. Installation of Optional Rear-Mounting Support Brackets Kit
Back of Unit
Rack Enclosure Threaded Rear Mounting Rail (typical)
Kit / Quantity
Part Number
KT/6228‐3
2
2
HW/10‐32SHLDR
4
4
HW/10‐32FLT
2
2
HW/10‐32SPLIT
2
2
HW/10‐32HEXNUT
4
4
HW/10‐32x1/2RK
2
–
FP/6138‐2
–
2
FP/6138‐3
Description
Shoulder Screw, #10
Flat Washer, #10
Lock Washer, #10
Hex Nut, #10
Bolt, #10, Rear Support Bracket
Bracket, Rear Support – 4"
Bracket, Rear Support – 10"
2–5
Revision 1
MN-CDM800
