CDM-800 Gateway Router
Serial-based Remote Product Management
Command
Parameter Number of
(Instruction
Type Arguments
& Qualifier)
Management N/A 12 bytes, alpha-
MAC Address numerical
GE1 MAC N/A 12 bytes, alpha-
Address numerical
GE2 MAC N/A 12 bytes, alpha-
Address numerical
Management MLC= 1 byte, value 0 thru
Link 5
Configuration
Actual N/A None
Negotiated Port
Speed
SNMP Read SRC= 16 bytes,
Community characters, no
spaces
SNMP SWC= 16 bytes,
Write characters, no
Community spaces
Description of Arguments
Query only.
Returns the unique MAC Address for the modem.
Example: MAC=00:06:B0:00:01:C2
Query only.
Returns the unique GE1 MAC Address.
Example: MG1=00:06:B0:00:01:C2
Query only.
Returns the unique GE2 MAC Address.
Example: MG2=00:06:B0:00:01:C2
Command or Query.
Management Interface mode, where:
0 = Auto Negotiate
1 = reserved
2 = 100Mbps – Full Duplex
3 = 100Mbps – Half Duplex
4 = 10Mbps – Full Duplex
5 = 10Mbps – Half Duplex
Query only.
Returns actual negotiated port speed in the form abcd, where:
a = GE 1 negotiated port speed.
b = GE 2 negotiated port speed.
c = the management port negotiated port speed.
a, b, c, d have the following values:
0 = Link down
1 = 100 Full
2 = 100 Half
3 = 10 Full
4 = 10 Half
5 = 1000 Full
Command or Query.
SNMP read community string. Empty string is not allowed
Example: <1/SRC=public
Command or Query.
SNMP write community string. Empty string is not allowed
Example: <1/SWC =public
N/A
N/A
N/A
MLC =
MLC?
MLC *
MLC #
N/A
SRC =
SRC!
SWC =
SWC!
6–11
MN-CDM800
Query
Response to
(Instruction & Response to Query
Command
Qualifier)
MAC? MAC=aabbccddeeff
(see Description of Arguments)
MG1? MG1=aabbccddeeff
(see Description of Arguments)
MG2? MG2=aabbccddeeff
(see Description of Arguments)
MLC? MLC =x
(see Description of Arguments)
NPS? NPS=abc
(see Description of Arguments)
SRC? SRC =x
(see Description of Arguments)
SWC? SWC =x
(see Description of
Arguments)
