Figure 4-2 Removing The Enclosure From The Rack - HP AlphaServer TS15 Owner's Manual

Removing the System Enclosure
1. As shown in Figure 4–2, remove the four screws
rack. Note the location of the mounting holes
CAUTION: The enclosure is heavy, not tethered, and will fall out if not handled carefully.
Grasp it firmly with both hands before sliding it from or into the rack.
Figure 4–2 Removing the Enclosure from the Rack
1
2
1
2. Slide the enclosure from the rack and place it on a tabletop.
3. As shown in Figure 4–3, remove the three M4 screws
enclosure and fully loosen the three captive screws
4. Rotate the enclosure so that the hinged edge is slightly overhanging the tabletop.
Lift up the captive screw side
the hinged side. Lift the cover straight up
NOTE: Notice the quick reference labels on the inside of the top cover. The labels provide
detailed information about the system.
4-4 hp AlphaServer TS15 Owner's Guide
that fasten the enclosure
.
4
3
MR0563
of the cover and disengage the tabs from the slots on
and set it on the tabletop.
on the hinged side
on the other side.
to the
of the
