Table 15---3 shows which options are available for each port. The sections that
follow describe the configuration settings you can change.

Table 15---3.

Port 1
X
X
X
X
X
X
X
15.4.1 Modes
The operational mode of the port. Each communications port operates in one of
the following modes:
Terminal mode
Calibration
System Config.
Computer
Remote Monitor Sends all system event information to an RMP , RIM, or SCM.
Port 1 and Port 2 cannot be in the same mode simultaneously; they must always
be operating in different modes. The modes are described later in this chapter.
15.4.2 Rate
The baud rate of the equipment connected to this port. The baud rate determines
the speed of data transferred between the UPS and the connected equipment.
For Remote Monitor mode, the baud rate must be set to 300. All other modes
should operate at the highest baud rate available with the connected equipment.
300 baud is not recommended for any mode except Remote Monitor.
You can select a baud rate of 300, 1200, 2400, 4800, 9600, or 19,200.
Powerware 9315 (500 kVA- -750 kVA) Installation and Operation
164201244 REV. D 030101
Options Available for Each Communication Port
Port 2
X Terminal Mode
X Calibration Mode
X System Configuration
X Computer Mode
Remote Monitor Mode
X Baud rate of 300, 1200, 2400, 4800, 9600, or 19200
X Data size/stop bits of 8/1 or 8/2
X Data size/stop bits of 7/1 or 7/2
X Disabled handshaking
X XON/XOFF handshaking
System events are logged immediately as they occur.
Used only by service personnel.
Allows you to set building alarms, battery tests, etc.
(Check with your Sales or Service Representative for availability.)
Provides a proprietary Binary Computer Mode (BCM) Interface
for Powerware facility monitoring or network communication via
ConnectUPS.
Available for Port 1 only.
Options
15--5
