This is a product for restricted sales distribution to informed partners. Installation restrictions or additional measures may be needed to prevent disturbances. ---------------------------------- SAVE THESE INSTRUCTIONS Conserver Ces Instructions concernant la sécurité. Powerware 9315 Maintenance Bypass Module 30-160kVA 164201177 Rev. C 041500...
(MBP). An optional UPS Module Input Bypass circuit breaker (BIB) is available. The MBM can be either free-standing or line-up-and-match. Figure 1 shows a typical MBM cabinet with isolation transformer for a Powerware 9315 30---160kVA UPS and MBM cabinet without isolation transformer for a Powerware 9315 30---160kVA UPS.
Rectangular boxes containing bold type are warnings or cautions that pertain to the system or its electrical connections. This important information indicates possible dangers pertaining to personnel safety, equipment damage, critical load protection, or operational concerns. Powerware 9315 Maintenance Bypass Module 30-160kVA 164201177 Rev. C 041500...
Contact the local Powerware Field Service office for information on how to obtain copies of these manuals. Getting Help If you have a question about any of the information in this manual, or if you have a...
Page 8
This Page Intentionally Left Blank. Powerware 9315 Maintenance Bypass Module 30-160kVA 164201177 Rev. C 041500...
Figure 2 shows the front and side view of the MBM with or without transformer for a Powerware 9315 30---160kVA module. The MBM is shipped as a separate item. Use a forklift or pallet jack to move the packaged cabinet to the installation site, or as close as possible to the site, before unloading.
Wiring should be installed through the bottom or top entry of the module. For UPS external wiring requirements, including minimum AWG size of external wiring, see the PowerwareÒ 9315 Installation manual provided with the UPS system. NOTE: Material and labor for external wiring are to be provided by designated personnel.
The first task in preparing for installation of the MBM is inspecting and unpacking the unit. The MBM arrives covered with protective packaging material as shown in Figure 3. Figure 3. MBM as Shipped, with Outer Packaging and Pallet Powerware 9315 Maintenance Bypass Module 30---160kVA 164201177 Rev. C 041500 OUTER PACKAGING...
Page 12
Please to refer to them. Remove the plastic bag and foam packing material. Please discard or recycle them in a responsible manner. Powerware 9315 Maintenance Bypass Module 30-160kVA 164201177 Rev. C 041500...
After the plywood/polyfoam skids clear the floor, remove the hardware loosened in step 3. Pull the skids out from under the MBM. Discard or recycle them in a responsible manner. Powerware 9315 Maintenance Bypass Module 30---160kVA 164201177 Rev. C 041500 in.).
Install the doors removed in step 1. The MBM is now ready to be rolled to its final location. FRONT SUPPORT SUPPORT JACKING BOLT (USE FRONT AND REAR) Figure 4. Detail of Shipping Supports Powerware 9315 Maintenance Bypass Module 30-160kVA REAR SUPPORT SIDE POLYFOAM SKID 164201177 Rev. C 041500...
Cable Entry, Top Plan View (Front) Cable Entry, Bottom Plan View Figure 5. Top, Bottom, and Front View of Maintenance Bypass Module Powerware 9315 Maintenance Bypass Module 30---160kVA 164201177 Rev. C 041500 Installing and Wiring the Maintenance Bypass Module Cooling Air Inlets...
Page 16
Details about power wiring are provided in the tables of Appendix A of this manual. Figure 6 shows typical power wiring terminations of the UPS module and Maintenance Bypass Module (30---160kVA). Refer to the Powerware 9315 Installation manual provided with the UPS system for location of UPS module cabinet wiring terminations.
MBM cabinet, for connecting to the UPS input and output terminals. Refer to Appendix A for UPS module to MBM wiring terminal locations. Line up and match connection (cables sold separately by Powerware) · From the UPS to the MBM, the power cables are connected by mechanical pressure lugs.
Page 18
This Page Intentionally Left Blank. Powerware 9315 Maintenance Bypass Module 30-160kVA 164201177 Rev. C 041500...
Such attempts may also invalidate your system warranty. Maintenance Bypass Module Operation The MBM is provided for use with the Powerware 9315 (30---160kVA) UPS module. WARNING: Only persons familiar with the operation of this equipment should transfer loads.
NOTE: While the UPS is in Normal Mode and the MIS breaker is closed, the MBP breaker always trips OFF. Likewise, while the UPS is in Normal Mode and the MBP is closed, the MIS breaker always trips OFF. CAUTION: CAUTION: CAUTION: Powerware 9315 Maintenance Bypass Module 30-160kVA 164201177 Rev. C 041500...
Insert key “A” into solenoid and turn key to LOCK position. Deenergize UPS before servicing (see UPS Operation manual). For UPS electrical isolation, BIB breaker (if applicable) must be opened. Powerware 9315 Maintenance Bypass Module 30---160kVA 164201177 Rev. C 041500 CAUTION:...
Page 22
Bypass power sources should be deenergized and verified with a meter before working in the required area. WARNING: UPS equipment has power feeds that are derived from two or more power sources. CAUTION: Powerware 9315 Maintenance Bypass Module 30-160kVA 164201177 Rev. C 041500...
More frequent intervals are recommended if the equipment is subjected to highly repetitive operations. CAUTION: Refer to Section 9 -- Maintaining the UPS System of the Powerware 9315 30-- 160kVA Operation manual, Powerware part number 164200252, before beginning maintenance or repairs on the UPS equipment.
Page 24
This Page Intentionally Left Blank. Powerware 9315 Maintenance Bypass Module 30-160kVA 164201177 Rev. C 041500...
164201177---10 Powerware 9315 Maintenance Bypass Module 30---160kVA 164201177 Rev. C 041500 Installation Notes Typical MBM Cabinet --- 30-160kVA with or without XFMR Typical UPS System with MBM Oneline --- 30-160kVA, Reverse Transfer (RT), 480:480VAC, 600:600VAC, 400:400VAC Oneline --- 30-160kVA, Reverse Transfer (RT), 480:208VAC,...
Page 26
(each) VOLTS AMPS map to drawing 164201177--- 5 (Reverse Transfer Connection) and DESCRIPTION: INSTALLATION NOTES DRAWING NO: REVISION: C Powerware 9315 Maintenance Bypass Module 30-160kVA Powerware 9315 Rating 60 Hz SHEET: 164201177---1 DATE: 041500 164201177 Rev. C 041500 1 of 4...
Page 27
(2) Conductors A, B, C, D, Note: Callout letters 164201177--- 7 (Parallel Connection). Read and understand the notes on drawings when planning your installation. Powerware 9315 Maintenance Bypass Module 30---160kVA 164201177 Rev. C 041500 Powereware 9315 , 480:480 /600:600 Units...
Page 28
VOLTS AMPS map to drawing 164201177--- 6 (Reverse Transfer Connection) and DESCRIPTION: DRAWING NO: REVISION: C Powerware 9315 Rating 60 Hz INSTALLATION NOTES SHEET: 164201177---1 DATE: 041500 Powerware 9315 Maintenance Bypass Module 30-160kVA 164201177 Rev. C 041500 3 of 4...
Page 29
CONTROL WIRING TO UPS (2) CONDUCTORS A, B, C, D, Note: Callout letters 164201177--- 7 (Parallel Connection). Read and understand the notes on drawings when planning your installation. Powerware 9315 Maintenance Bypass Module 30---160kVA 164201177 Rev. C 041500 , 380:380 400:400 VAC, UNITS...
Page 31
1. MBM 50/30---20/20 means MBM cabinet, Family 50, 208V (input) and 208V (output), model 30 (30kVA). 2. All breakers are 100% UL rated with Interrupting Capacity (IC) of 65kAIC@480VAC. Powerware 9315 Maintenance Bypass Module 30---160kVA 164201177 Rev. C 041500 , 380:380 , 400:400 , 600:208...
Page 33
Control wiring from each UPS Module should be twisted. ---1 Twist Pair ---12 ---13 ---14 Figure 1. (Reverse Transfer) Powerware 9315 Maintenance Bypass Module 30---160kVA 164201177 Rev. C 041500 Reverse Transfer (RT) System. Size of Connection Recommended Pressure Point in UPS...
Page 34
Dimensions are in millimeters (inches) A ---10 DESCRIPTION: TYPICAL MBM CABINET -- 30-160kVA with or without XFMR DRAWING NO: 164201177---2 REVISION: DATE: Powerware 9315 Maintenance Bypass Module 30-160kVA SHEET: 1 of 3 080498 164201177 Rev. C 041500...
Page 35
Powerware 9315 Maintenance Bypass Module 30---160kVA 164201177 Rev. C 041500 BREAKER ANNUNCIATION BIB1 BIB2 TYPICAL MBM CABINET -- DESCRIPTION: 30-160kVA with or without XFMR INTERIOR COMPONENTS DRAWING NO: REVISION: UTILITY INPUT, IF BIB BREAKER IS INSTALLED CRITICAL LOAD CONNECTIONS UPS/PTC OUTPUT...
Page 36
Dimensions are in millimeters (inches) A ---12 BOTTOM VIEW DESCRIPTION: TYPICAL MBM CABINET -- 30-160kVA with or without XFMR TOP and BOTTOM VIEW DRAWING NO: REVISION: Powerware 9315 Maintenance Bypass Module 30-160kVA SHEET: 164201177---2 DATE: 080498 164201177 Rev. C 041500 3 of 3...
Page 37
PDM CABINET MBM CABINET (optional) Powerware 9315 Maintenance Bypass Module 30---160kVA 164201177 Rev. C 041500 INPUT (optional) TRANSFORMER CABINET (optional) 30---160kVA UPS System with MBM DESCRIPTION: DRAWING NO: REVISION: BATTERY CABINET CABINET (optional) TYPICAL UPS SYSTEM WITH MBM SHEET: 164201177---3...
Page 38
SOLENOID KEY RELEASE UNIT (MECHANICAL INTERLOCK) REVERSE TRANSFER A ---14 DESCRIPTION: ONELINE -- 30-160kVA, RT, 480:480VAC, 600:600VAC, 400:400VAC DRAWING NO: 164201177---4 REVISION: 110100057 D3 Powerware 9315 Maintenance Bypass Module 30-160kVA SHEET: 1 of 1 DATE: 080498 164201177 Rev. C 041500...
Page 44
Applicable to POWERWARE 9315 30---160 kVA UPS modules only. 160kVA UPS is shown. DESCRIPTION: LINE UP AND MATCH ARRANGEMENT #1 DRAWING NO: SHEET: 164201177---10 1 of 4 REVISION: DATE: 080498 Powerware 9315 Maintenance Bypass Module 30-160kVA A ---20 164201177 Rev. C 041500...
Page 45
(NOTE 4) LINE UP AND MATCH ARRANGEMENT #2 Applicable to POWERWARE 9315 30---160 kVA UPS modules only. 160kVA UPS is shown. Powerware 9315 Maintenance Bypass Module 30---160kVA 164201177 Rev. C 041500 (NOTE 5) (NOTE 2) DESCRIPTION: LINE UP AND MATCH ARRANGEMENT #2...
Page 46
Applicable to POWERWARE 9315 30---160 kVA UPS modules only. 160kVA UPS is shown. DESCRIPTION: LINE UP AND MATCH ARRANGEMENT #3 DRAWING NO: SHEET: 164201177---10 3 of 4 REVISION: DATE: 080498 Powerware 9315 Maintenance Bypass Module 30-160kVA A ---22 164201177 Rev. C 041500...
Page 47
External wiring is required and supplied by others. The PDM cabinet is applicable IF AND ONLY IF the MBM and UPS module outputs are 3 phase, 60Hz, 280VAC. Refer to Powerware 9315 UPS module installation manual for proper terminating lugs. Powerware 9315 Maintenance Bypass Module 30---160kVA 164201177 Rev.
Page 48
This Page Intentionally Left Blank. Powerware 9315 Maintenance Bypass Module 30-160kVA A ---24 164201177 Rev. C 041500...
