11.6.1 System Meters Screen

Figure 11---3 shows the LCD screen as it appears when you first start the UPS. The
Meters menu is displayed in the menu box, with the System option highlighted. In
the information area, the system meters show their current readings.
System Normal
ALARM:
NOTICES: NONE
Battery
Minutes
Meters
System
Load Amps
Versions
Meters
The Input area shows the phase-to-phase voltage, frequency, and phase current
of the incoming utility, followed by the KVA, KW, and power factor measurements.
The output area shows the same information for the power being output by the
UPS.
The Bypass area shows the phase-to-phase voltage of the bypass source. The
Battery area displays the DC voltage (V) and the DC current (I).
11--6
Uninterruptible Power System
NONE
48.5
VAB
nnn
IA
nnn
KVA
nnn
VAB
nnn
Events Statistics Graphics Setup
Figure 11 ---3. System Meters Screen
Input
VBC VCA FREQ
nnn nnn nn.n
IB IC
nnn nnn
KW PF
nnn 0.nn
Bypass
VBC VCA
nnn nnn
Powerware 9315 (500 kVA- -750 kVA) Installation and Operation
4 MAY 1999 09:25:42
Output
VAB VBC VCA FREQ
nnn nnn nnn nn.n
IA IB IC IN
nnn nnn nnn nnn
KVA KW PF
nnn nnn 0.nn
Battery
V I
nnn + nn
164201244 REV. D 030101
