Powerware Uninterruptible Power Supply Installation And Operation Manual page 162

REAR
A ---26
INPUT/RECTIFIER SECTION---PCM 1
FRONT
LEFT SIDE
DESCRIPTION:
LOCATION OF UPS TERMINALS
DRAWING NO:
164201244---7
REVISION:
A
Powerware 9315 (500 kVA- -750 kVA) Installation and Operation
CUSTOMER
ACCESS
PANEL
E4
(POS)
DC Source Input
E5
(NEG)
E1
A)
4 (
E2
B)
4 (
AC Source Input
E3
C)
4 (
GND
SHEET:
DATE:
051599
164201244 REV. D 030101
2 of 6
