16.6 UPS Setup Configuration

Connect the modem to the UPS by connecting one end of the serial cable to the
UPS Port 2 DB---25F connector and the other to the modem (refer to Chapter 13,
"Serial Communications"). If using a standard serial cable, a null modem adapter
is required for the connection to the modem.
The Powerware 9315 UPS can only use serial Port 2, DB---25F, for the Remote
Notification option. This connection is located on the Customer interface Panel at
the top right of the UPS cabinet.
The remote modem operates at only 2400 baud.
Following the instructions in Chapter 9, "Using the Control Panel" and Chapter 13,
"Serial Communications", use the LCD screen and pushbuttons on the Monitor
Panel to access the setup screen and configure Port 2 as follows.
NOTE: The modem should be connected to the UPS as described in the modem
manufacturer's manual before configuring the UPS communications port.
<MODE>
<RATE>
<DATA/STOP>
<HANDSHAKING>
<SAVE>
The handshaking feature listed is for UPS-to-terminal handshaking, not
UPS-to-modem handshaking. Setting the handshaking to "modem" has no effect.
If the remote terminal has buffering problems because of excessive data transfer
rate from the UPS, XON/XOFF handshaking can be selected to resolve this issue.
The user must make sure that the modem (not the remote terminal) at the remote
terminal end of the connection is configured for either hardware handshaking or
none at all. This is required so that the modem does not attempt to trap the
XON/XOFF characters and prevent them from being transmitted to the UPS.

16.6.1 User Selected Events

Insert a check at each alarm or notice in the appropriate Group 1 or Group 2 block
to indicate the configuration of your UPS.
Powerware 9315 (500 kVA- -750 kVA) Installation and Operation
164201244 REV. D 030101
Remote Notify
The baud rate at which the modem will communicate
to other modems, 2400 baud.
8 1 Standard 8 data bits, 1 stop bit, no parity.
Disabled
Yes. To save new configuration.
