Introduction

Congratulations on your purchase of a Powerware 9315 (500 kVA---750 kVA)
Uninterruptable Power Supply! The Powerware online power protection system is
used to prevent loss of valuable electronic information, minimize equipment downtime,
and/or minimize the adverse effect on equipment production due to unexpected power
problems.
The Powerware UPS System continually monitors incoming electrical power and
removes the surges, spikes, sags, and other irregularities that are inherent in
commercial utility power. Working with your building's electrical system, the UPS
System supplies clean, consistent power that your sensitive electronic equipment
requires for reliable operation. And during brownouts, blackouts, and other power
interruptions, optional battery strings provide emergency power to safeguard your
operation.
The UPS system is housed in a free-standing cabinet, divided into three sections to
facilitate shipping. The cabinet sections line up and match in style and color, and have
safety shields behind the doors for hazardous voltage protection. The following
illustration depicts a typical Powerware 9315 (500 kVA---750 kVA) UPS System.
Powerware 9315 (500 kVA- -750 kVA) Installation and Operation
164201244 REV. D 030101
INPUT
RECTIFIER
CABINET
Typical Powerware 9315 (500 kVA---750 kVA) UPS System
OUTPUT
INVERTER
CABINET
MODULE
BYPASS
CABINET
