11.6 Using the Menu Options

The UPS menus allow you to display data in the information area to help you
monitor and control UPS operation. The following menus and options are
available:
·
Meters
·
Events
·
Statistics
·
Graphics
·
Setup
Powerware 9315 (500 kVA- -750 kVA) Installation and Operation
164201244 REV. D 030101
Displays performance meters for the system or critical load.
Displays the list of Active System Events and a historical log of
system events.
Displays statistical information about UPS operations for the
battery, load, or line.
Displays a real-time graphic representation of the flow of current
through the internal UPS components.
Allows you to configure the UPS communications port and set
the date and time for the time stamp.
11--5
