[2] Magnification

The preset and userset ratios are used to reduce and enlarge the original image to
accommodate copy paper size, and are available on the Basic Screen.
NOTE:
Normally, users are allowed to change the three USERSETs in the bottom
line on the Userset Magnification Setting Screen. The preset keys in the top
and middle lines can also be programmed in 2-5 DIPSW mode; however,
changing them is not recommended.
❒ Setting options:Userset or Preset ratio
❒ Default setting: USERSET1: 2.00
USERSET2: 4.00
USERSET3: 0.50
Preset Key Setting Menu Screen
Procedure
1 Touch [3] Preset key on the Key Operator Mode Screen to display the Preset Key Set-
ting Menu Screen.
2 Touch [3] Magnification to display the Userset Magnification Setting Screen.
3 Touch the USERSET you want to change, then enter a ratio from 0.25~4.00, using the
keypad.
If a ratio under 0.25 is entered, 0.25 will be displayed.
If a ratio over 4.00 is entered, 4.00 will be displayed.
4 Touch OK to complete the setting and return to the Preset Key Setting Menu Screen.
5 Touch RETURN to restore the Key Operator Mode Screen.
6 If no further changes are required, touch RETURN to restore the Basic Screen to
perform copying operations.
[3] Preset Key (continued)
Userset Magnification Setting Screen
Key Operator
Mode
System Initial
Copier Initial
Preset Key
E.K.C.
Lock Job
Memory
Paper Type
Panel Contrast
Key Operator
Data
Weekly
Timer
Touch Panel
Adjustment
Power Save
Memory
Switch
List Print
Application
Customize
Density Shift
KRDS Host
11
Key Operator
Mode
11-17
