Selecting Magnification Ratio (Lens Mode) (continued)

To Copy in Zoom Mode

Use the Zoom mode to reduce or enlarge the copied original image in 1% increments.
>>> Specification for Zoom Mode <<<
Zoom range: 25% to 400%
Incompatible Conditions: AMS, Repeat mode in Repeat, Reduce & Shift in Image Shift
1.
Touch ZOOM on the Basic Screen.
The popup menu for setting a zoom ratio will be displayed.
When starting a new copying job, be sure to close the RADF securely, then
press [AUTO RESET].
2.
Touch the Vertical/Horizontal zoom key on the popup menu, if it is not
highlighted, then set the desired zoom ratio.
Use the keypad on the popup menu to enter the desired magnification ratio
in 3 digits, or use arrows (
If an incorrect ratio is entered, continue by entering the correct 3-digit ratio.
3.
Touch OK.
The popup menu disappears automatically and the specified zoom ratio will be
displayed on the Basic Screen.
4.
Select additional copy conditions, as desired.
5.
Enter the desired print quantity from the control panel keypad.
See p. 3-7 for details on setting print quantity.
6.
Position original(s).
See p. 3-2 to p. 3-6 for details on positioning originals.
7.
Press [START].
3-14
Reminder!
DETAILS
HINT
HINT
c d
/ ) to scroll to the desired ratio.
