imagistics DF200 Operating Manual page 41

Duplexing Document Feeder 9729
1 Document Exit Tray
Misfeed Clearing Guide
2
3 Document Feed Tray
4 Document Guide Plate
Single Feed Tray
5
Automatic Document Feeder AF-9
Print Lamp
6
7 Misfeed Clearing Guide
Document Guide Plate
8
9 Feed Tray Extender
10 Document Exit Tray
Document Stopper
11
Original Cover 4011015302
Original Pad
12
Duplex Unit 9752
Lock Release Lever
13
14 Duplex Unit
Paper Feed Unit 9867/Paper Feed Unit 9753
15 Drawer
16 Drawer
Large Capacity Cabinet 9866
Drawer
17
: Receives originals which have been scanned by the machine.
: Open when clearing an original that has been misfed. p.10-22
: Load the originals to be scanned face up on this tray.
: Slide the guide plate to the size of the originals.
: Insert a single sheet into this tray to make a copy or copies of it.
: Lights green while the original is being scanned. Lights orange when a
trouble occurs.
: Open when clearing an original that has been misfed. p.10-23
: Slide the guide plate to the size of the originals.
: Slide this extender out when placing originals of large size.
: Receives originals which have been scanned by the machine.
: Slide this stopper out whenever originals of a large size have been
loaded.
: Holds the original placed on the Original Glass in position.
: Used to open the Duplex Unit to clear a misfed sheet of paper.
p.10-21
: Automatically turns over 1-sided copies to print data on both sides.
: Holds up to 500 sheets of paper. p.10-5
* The drawer lamp starts blinking when paper in the drawer is low and
lights orange steadily as soon as it runs out.
: Holds up to 500 sheets of paper and easily adjusts to different paper
sizes. p.10-6
* The drawer lamp starts blinking when paper in the drawer is low and
lights orange steadily as soon as it runs out.
: Holds up to 2,500 sheets of paper. p.10-7
2-13
2. System Overview
