NOTES
• When the Clear key is pressed, it clears the size
figure entered.
• When the 16-9/16 inch to 17 inch is set for X,
the maximum size that can be set for Y becomes
11 inch.
• When the 11-11/16 inch to 11-11/16 inch is set
for Y, the maximum size that can be set for X
becomes 16-1/2 inch.
7
Touch [ ] or [ ] to set the whole number
for Y and touch [Y]. The underline moves to
the fractional part. Set the fraction with [ ]
or [ ]. Now the value for Y has been fixed.
8
Touch [1] or [2].
NOTE
When a new paper size is stored, the old one is
cleared.
9
Touch [Enter].
1. When the Message "Replenish paper." Appears
4017P173EA
4017P174EA
10-9
