10-12

3. When the Message "Stapler empty." Appears

Reloading the Staple Cartridge

Finisher 9747
1
Holding the Grip, slide the Finisher away
from the machine.
2
Open Misfeed Clearing Guide [FN7] at the
right side of the Finisher.
3
Turn the dial to the left to move the Staple
Units toward the center.
The message shown on the left appears when the
staples are running low.
Reload the Staple Cartridge with a new clip by
following the procedure given below.
4017P178EA
4
Pull the Staple Cartridge out to the front.
4015O087AB NOTE
Two Staple Cartridges are mounted in Finisher
9747. Be sure to remove the specific Staple
Cartridge that is indicated in the message on the
Touch Panel.
5
Press the portion marked with Push of the
Staple Cartridge to pop up the upper part of
the cartridge and remove the empty clip.
FN7
4015O088AB
4002O177AB
Stapler 1
Stapler 2
4002O178AA
4002O362AA
