- Page 1 UDS1100 Quick Start Guide For the latest documentation, FAQs and firmware updates, visit www.lantronix.com...
- Page 2 UDS1100...
-
Page 3: Table Of Contents
UDS1100 QUICK START CONTENTS What’s In the Box ............2 Pinouts . -
Page 4: What's In The Box
POWER SUPPLY (INTERNATIONAL UNITS) PART # COMPONENT DESCRIPTION 520-080-R* Power cube, 100-240VAC, with international adapters 500-163 Serial Cable Power Cord Restraint * Not included with UDS1100 POE version DOCUMENTATION: CD-ROM containing User Guide and software utilities and Quick Start Guide. -
Page 5: Pinouts
DeviceInstaller software. For more detailed information or alternative configuration methods, refer to the User Guide on the CD. PINOUTS *Not included in UDS1100 POE version W W W . L A N T R O N I X . C O M... -
Page 6: Ip Addressing
IP your unit has been assigned by the DHCP server and add it to the list of Lantronix devices on the network. If the UDS does not acquire an IP, or you do not use DHCP, you must assign a fixed IP address. -
Page 7: Connect
1. Connect a serial device to your unit. 2. Connect an Ethernet cable to the RJ45 port. 3. For standard UDS1100 units, supply power to your unit using the power supply that was included in the packaging. 4. For the UDS1100-POE version, power is supplied to your unit over the Ethernet interface using an 802.3af POE compliant power source such as a POE mid-... -
Page 8: Assign Ip Address And Configure
U D S 1 1 0 0 ASSIGN IP ADDRESS AND CONFIGURE 1. Click the Start button on the Task Bar and select Programs ‹ Lantronix ‹ DeviceInstaller ‹ DeviceInstaller. The DeviceInstaller window displays. 2. Note the device IP address. -
Page 9: Leds/Troubleshoot
LEDS/TROUBLESHOOT The unit contains the following LEDs: • Power • 10/100 Mb Link • 10/100 Activity • Diagnostics • Status Channel 1 Simultaneously lit red and green LEDs means something is wrong. If the red LED is lit or blinking, count the number of times the green LED blinks between its pauses. - Page 10 Q u i c k S t a r t G u i d e U D S 1 1 0 0 SERIAL LEDS MEANING 10/100 Mb Link steady green Valid network connection 10/100 Activity blinking Network packets transmitting and receiving Diagnostic steady red and 3 blinks = Network controller error status blinking green...
-
Page 11: Contact
CONTACT For questions and technical support, please check our online knowledge base at www.lantronix.com/support For the latest documentation, FAQs and firmware updates, visit www.lantronix.com Lantronix, Inc. 7535 Irvine Center Drive Suite 100 Irvine, CA 92618, USA Toll Free: 800-526-8766 Phone: 949-453-3990 Fax: 949-453-3995 www.lantronix.com... - Page 12 UDS1100 2020 Copyright © Lantronix is a trademark of Lantronix. All rights reserved. 900-418 Rev. D 1/20...
