Processor Land Listing
Table 8-2. Land Number (Sheet 7 of 48)
Land No. Land Name
AJ9 VSA
AK10 VSS
AK12 VSS
AK14 VSS
AK16 VSS
AK2 VSS
AK4 VSS
AK42 VSS
AK44 VSS
AK46 VSS
AK48 VSS
AK50 VSS
AK52 TXT_AGENT
AK54 PE2B_TX_DN[5]
AK56 PE2C_RX_DN[8]
AK58 PE2C_RX_DP[9]
AK6 VSS
AK8 VSS
AL1 VCC
AL11 VCC
AL13 VCC
AL15 VCC
AL17 VCC
AL3 VCC
AL43 VSS
AL45 VSS
AL47 BMCINIT
AL49 VSS
AL5 VCC
AL51 VSS
AL53 VSS
AL55 RSVD
AL57 PE2C_RX_DN[10]
AL7 VCC
AL9 VCC
AM10 VCC
AM12 VCC
AM14 VCC
AM16 VCC
AM2 VCC
AM4 VCC
AM42 VTTD
Intel® Xeon® Processor E5-1600/E5-2600/E5-4600 Product Families
Datasheet Volume One
Buffer Type Direction
PWR
GND
GND
GND
GND
GND
GND
GND
GND
GND
GND
GND
CMOS I
PCIEX3 O
PCIEX3 I
PCIEX3 I
GND
GND
PWR
PWR
PWR
PWR
PWR
PWR
GND
GND
CMOS I
GND
PWR
GND
GND
PCIEX3 I
PWR
PWR
PWR
PWR
PWR
PWR
PWR
PWR
PWR
Table 8-2. Land Number (Sheet 8 of 48)
Land No. Land Name
AM44 RSVD
AM46 PE3D_RX_DP[14]
AM48 VTTA
AM50 PE2A_TX_DP[1]
AM52 PE2A_TX_DP[3]
AM54 VTTA
AM56 VSS
AM58 PE2C_RX_DN[9]
AM6 VCC
AM8 VCC
AN1 VCC
AN11 VCC
AN13 VCC
AN15 VCC
AN17 VCC
AN3 VCC
AN43 CPU_ONLY_RESET
AN45 PE3D_RX_DP[15]
AN47 PE3D_RX_DP[13]
AN49 PE2A_TX_DP[0]
AN5 VCC
AN51 PE2A_TX_DP[2]
AN53 PE2B_TX_DP[6]
AN55 VSS
AN57 VSS
AN7 VCC
AN9 VCC
AP10 VCC
AP12 VCC
AP14 VCC
AP16 VCC
AP2 VCC
AP4 VCC
AP42 VSS
AP44 VSS
AP46 PE3D_RX_DN[14]
AP48 RSVD
AP50 PE2A_TX_DN[1]
AP52 PE2A_TX_DN[3]
AP54 PE2B_TX_DP[7]
AP56 PE2D_RX_DP[13]
AP58 VSS
Buffer Type Direction
PCIEX3 I
PWR
PCIEX3 O
PCIEX3 O
PWR
GND
PCIEX3 I
PWR
PWR
PWR
PWR
PWR
PWR
PWR
PWR
ODCMOS I/O
PCIEX3 I
PCIEX3 I
PCIEX3 O
PWR
PCIEX3 O
PCIEX3 O
GND
GND
PWR
PWR
PWR
PWR
PWR
PWR
PWR
PWR
GND
GND
PCIEX3 I
PCIEX3 O
PCIEX3 O
PCIEX3 O
PCIEX3 I
GND
