Dts: 6-Core 95W Thermal Profile 1U; Core 95W Thermal Profile Table 1U - Intel Xeon Processor E5-1600 Datasheet

Figure 5-14. DTS: 6-Core 95W Thermal Profile 1U
Notes:
1. Some processor units may be tested to lower TDP and the TEMPERATURE_TARGET MSR will be aligned to
that lower TDP.
2. Please refer to
3. Refer to the Intel® Xeon® Processor E5-1600/E5-2600/E5-4600 Product Families Thermal/Mechanical
Design Guide for system and environmental implementation details.
Table 5-13. 8/6-Core 95W Thermal Profile Table 1U (Sheet 1 of 2)
Power (W)
0
5
10
15
20
25
30
35
40
45
50
55
60
65
70
75
80
118
Table 5-13 for discrete points that constitute this thermal profile.
Maximum T (°C)
CASE
8/6-core
52.2
53.3
54.4
55.5
56.6
57.7
58.8
59.9
61.0
62.1
63.2
64.2
65.3
66.4
67.5
68.6
69.7
Intel® Xeon® Processor E5-1600/E5-2600/E5-4600 Product Families
Thermal Management Specifications
Maximum DTS (°C)
8-core
52.2
53.9
55.5
57.2
58.9
60.6
62.2
63.9
65.6
67.2
68.9
70.6
72.2
73.9
75.6
77.3
78.9
Datasheet Volume One
6-core
52.2
53.9
55.7
57.4
59.1
60.8
62.6
64.3
66.0
67.7
69.5
71.2
72.9
74.6
76.4
78.1
79.8
