8-Core 150W Thermal Profile, Workstation Platform Sku Only - Intel Xeon Processor E5-1600 Datasheet

2. This Thermal Profile is representative of a volumetrically unconstrained platform. Please refer to
for discrete points that constitute the thermal profile.
3. Implementation of this Thermal Profile should result in virtually no TCC activation. Refer to the Intel®
Xeon® Processor E5-1600/E5-2600/E5-4600 Product Families Thermal/Mechanical Design Guide for
system and environmental implementation details.
Table 5-3.

8-Core 150W Thermal Profile, Workstation Platform SKU Only

106
Power (W)
0
5
10
15
20
25
30
35
40
45
50
55
60
65
70
75
80
85
90
95
100
105
110
115
120
125
130
135
140
145
150
Thermal Management Specifications
Maximum T (°C)
CASE
38.9
39.8
40.8
41.7
42.6
43.6
44.5
45.4
46.4
47.3
48.3
49.2
50.1
51.1
52.0
52.9
53.9
54.8
55.7
56.7
57.6
58.5
59.5
60.4
61.3
62.3
63.2
64.1
65.1
66.0
67.0
Intel® Xeon® Processor E5-1600/E5-2600/E5-4600 Product Families
Table 5-3
Maximum DTS(°C)
38.9
40.4
42.0
43.5
45.0
46.6
48.1
49.6
51.1
52.7
54.2
55.7
57.3
58.8
60.3
61.9
63.4
64.9
66.4
68.0
69.5
71.0
72.6
74.1
75.6
77.2
78.7
80.2
81.7
83.3
84.8
Datasheet Volume One
