System Board - Intergraph InterServe 80 SL System Reference Manual

74
Feature
Memory
Expansion
Networking
SCSI
EIDE
Mouse
Keyboard
Graphics
System Disk
Drive
CD-ROM
I/O Slots
Peripheral Bays
I/O Ports
Power Supply

System Board

The following table lists the main chip components on the MSMT511 system board.
Component
System BIOS
Processor
Description
64 MB, 128 MB, or 256 MB increments
10/100BaseT/TX Ethernet
One dual channel, 16-bit, Fast-20 Wide SCSI-3 controller for internal
and external SCSI devices
Primary EIDE port for CD-ROM (standard)
Primax 3-Button Mouse
PS/2 style - Standard 104 key
Matrox G100
4.3 GB or 9.1 GB or 18.2 GB 7,200 or 10,000 RPM (Wide Ultra,
SMART)
32X (standard) or 4X/2X SCSI CD Writer
Four full-length PCI, one full-length PCI/ISA, one full-length
Accelerated Graphics Port (AGP)
Three 3.5-inch x 1-inch or two 3.5-inch x 1.6-inch internal bays for
system disk and optional disks
One 3.5-inch x 1.0-inch external bay for floppy drive
One 5.25-inch x 1.6-inch external bay for CD-ROM
Two 5.25-inch x 1.6-inch external bays for optional devices
One PS/2 Mouse Port and one PS/2 Keyboard Port
One Parallel Port, EPP- and ECP-compatible
Two Serial (COM) Ports
MIDI/Game Port
Two Universal Serial Bus (USB) Ports
250 Watts, manual-ranging
Description
Phoenix BIOS
Intel Pentium II; 266 MHz, 300 MHz, 333 MHz, 350 MHz, or
400 MHz SEC (Single Edge Connector)
