Intergraph InterServe 80 SL System Reference Manual page 25

Tab
(3 each side)
Light pipe
Standoff posts
(4 each side)
5. Pull the face panel away from the chassis slightly to ensure all tabs are released.
6. Grasp the left side of the face panel and pivot it left to expose the standby switch and
cable.
7. Spread the standby switch mount locking tabs, grasp the switch, and pull the switch out
of its mount.
8. Turn the face panel downward until the standby switch button drops out.
9. Place the left side of the new face panel near the left front of the chassis and orient the
standby switch so that the black and green wires are at the bottom.
10. Push the standby switch into the mount until it snaps into place.
11. Place the standby switch button into its hole and push firmly until it seats.
12. Align the new face panel with the tab notches and light pipe guides, and carefully push
the panel onto the chassis until all tabs engage.
13. Install the door, left and right side panels, and top cover.
To replace a side plastic cowling:
1. Remove the top cover, then remove the side panel that has the plastic you want to
replace. See Chapter 1, "Accessing the Components," for details.
2. Place the side panel, with the cowling side down, on a flat, padded surface.
3. Remove the screw that secures the plastic to the side panel.
Tab
(3 each side)
Switch mount
locking tabs
13
