50
Power Supply Cable Routing and Pinouts
The following table lists the cable connectors from the power supply that connect to the
system board and other devices.
Connector
P1
P2, P3, P5
P4
P6
P1 Pinout
Pin
Signal
1
+3.3V
2
+3.3V
3
Ground
4
+5V
5
Ground
6
+5V
7
Ground
8
Powergood
9
5V Standby
10
+12V
P2 - P5 Pinouts
Pin
Signal
1
+12V
2
Ground
P6 Pinout
Pin
Signal
1
+5V
2
Ground
Device
J27 on System board
Disk Drive/CD-ROM
MCBL172A Chassis Fan
Floppy Disk Drive
Wire Color
Orange
Orange
Black
Red
Black
Red
Black
Gray
Purple
Yellow
Wire Color
Yellow
Black
Wire Color
Red
Black
Notes
Via cable MCBL173A
Pin
Signal
11
+3.3V/+3.3V sense
12
-12V
13
Ground/3.3V sense
14
Remote On
15
Ground
16
Ground
17
Ground
18
-5V
19
5V
20
5V
Pin
Signal
3
Ground
4
+5V
Pin
Signal
3
Ground
4
+12
Wire Color
Orange/Brown
Blue
Black/Black
Green
Black
Black
Black
White
Red
Red
Wire Color
Black
Red
Wire Color
Black
Yellow
