See the System Setup document and Hardware Monitor's online Help for more information
on InterSite Hardware Monitor.
The top LED on the front panel indicates the following power states of the system:
LED Power State
Green Working
Amber Suspend
Off Mechanical
Off
If the power cord is plugged in, but the LED is off, then the system has a power voltage
problem. Call the Customer Response Center at 1-800-633-7248 for assistance.
Refer to the System Setup for information about using the Automatic Shutdown Utility.

Intrusion Alert Switch

The intrusion alert switch (CSWX308) is mounted at the top left side of the system near the
front. This microswitch is the only replaceable component in the hardware monitoring
system. If you detach the side panel when the system is off, the event is registered in the
InterSite Hardware Monitor software. See Chapter 2, "Servicing the System," for details on
replacing the switch. See also InterSite Hardware Monitor Help for details.

Optional Hardware

If your system includes any of the following hardware, see the documentation delivered with
that hardware for additional information:
u
AMI RAID controller
u
InterRAID-8e disk array cabinet
u
Graphics card
u
Monitor
u
External or internal peripherals
Description Explanation
On System is fully usable; power conservation is on a
per-device basis.
Suspend System can be powered through Wake-On-LAN.
Off No power consumption. The system is
disconnected from AC power.
To return the system to the Working state, you
must reconnect the power cord and perform a full
system shutdown and restart using the Automatic
Shutdown Utility.
