To close the base unit:

1. Place the side panel on the chassis so that all tabs on the back of the chassis insert into

their slots.

NOTE

When installing the left side panel, ensure that the security tab aligns with its corresponding

slot on the panel.

2. Push the side panel toward the front of the chassis, then push down to seat the panel.

3. Repeat steps 1 and 2 above to install the remaining side panel, if necessary.

4. Place the top cover on the chassis so that all tabs are inserted into their slots.

5. Slide the top cover forward until it locks into place.

CAUTION

After servicing or upgrading the system, always replace the covers that were removed. The

covers ensure the system maintains proper air flow, so internal components do not overheat

and fail. The covers also ensure that electromagnetic interference (EMI) emissions remain

below the standard requirements.
