J28 (1, 2) - MCBL128A, Power (Standby) Switch Cable Pinout
Pin
Signal
1
+5V trickle
J28 (15, 16) - MCBL130A, Disk Activity LED Cable Pinout
Pin
Signal
1
DiskActive
J28 (18, 20) - MCBL129A, Hard Disk Drive Power On LED Cable Pinout
Pin
Signal
1
PwrGood
J28 (24, 27) - MCBLW66, Speaker Cable Pinout
Pin
Signal
1
Speaker+
J34 - MCBL251A, Intrusion Alarm Switch Cable Pinout
Pin
Signal
1
Alarm
Wire Color
Pin
White
2
Wire Color
Pin
Orange
2
Wire Color
Pin
White
2
Wire Color
Pin
Red
2
Wire Color
Pin
Red
2
Signal
Wire Color
PWRBTN
Green
Signal
Wire Color
Ground
Black
Signal
Wire Color
Ground
Black
Signal
Wire Color
Speaker -
White
Signal
Wire Color
Ground
Black
