To disable SCSI termination, remove the TE jumper from connector J2. To enable parity,
remove the PD jumper from connector J2. For optimum performance, remove all jumpers
from J2.
Use jumpers as defined in the following table to set the SCSI ID.
SCSI ID
0
1
2
3
EIDE CD-ROM Drive (CDSK177)
The following figure shows the back of the EIDE CD-ROM drive.
Device Connector
EIDE
Power
The Mode Select header is set to Master as shown.
ID1
ID2
ID4
ID8
OFF
OFF
OFF
OFF
ON
OFF
OFF
OFF
OFF
ON
OFF
OFF
ON
ON
OFF
OFF
Mode Select
(Set to Master)
Cable
MCBL252A
P4
SCSI ID
ID1
4
OFF
5
ON
6
OFF
EIDE
Connector
Connects to
J8, Secondary EIDE, System Board
Power Supply
69
ID2
ID4
ID8
OFF
ON
OFF
OFF
ON
OFF
ON
ON
OFF
Power
Connector
