42
5. Do all of the following:
Set the SCSI ID on the new drive to an unused ID number.
Disable termination on the new drive.
See Chapter 6, "Peripherals," for details on these tasks.
6. Attach the bracket to the new drive.
Alignment tabs
Rear mounting tab
7. Insert the alignment tabs into the appropriate slots in the chassis.
Drive
Front mounting
tabs
Screw holes for front
mounting tabs
