External Ports
The following figure shows the external ports on the back of the unit.
Keyboard
Universal
Serial Bus
1 & 2
Serial
(COM 1)
Serial
(COM 2)
Parallel
Line Out
Line In
Microphone
Keyboard, Mouse
The Keyboard and Mouse ports are PS/2 style, 6-pin ports. They are not
interchangeable.
2
1
3
4
6
5
Mouse
MIDI/Game
Pin
Signal
1
KDATA (keyboard)
MDATA (mouse)
2
Spare
3
Ground
4
VCC
5
KCLK
6
Spare
59
