62
Line In
The Line In port connects audio input devices, such as a tape deck or a CD player, to the
computer.
2
Microphone
The Microphone port connects the microphone jack of the NMB multimedia keyboard
to the computer. You can also use the port to connect a headset microphone to the computer.
2
Pin
5
1
2
5
1
5
Pin
1
2
5
1
Signal
Ground
Left Channel In
Right Channel In
Signal
Ground
MIC 2
MIC 1
