Configuration Options via Command Line (Cont.)
(Continued from previous page)
2. At the Enter STB number [#]> command, type the number of the PIVD100R X-Port
connected to the STB for which you wish to modify configuration. Then, press Enter.
3. (Dual tuner STB only) At the Enter tuner number (1 or 2) [1]> command, either
press Enter to accept the default value in square brackets, or type the appropriate tuner
number and press Enter.
4. At the Enter multicast IP address [227.0.0.0]: command, either press Enter
to accept the default value in square brackets, or type the appropriate multicast IP address
for this stream and press Enter.
5. At the Enter new multicast port [1234]> command, either press Enter to accept
the default value in square brackets, or type the appropriate port number for the multicast
stream and press Enter.
6. After you type the port number, the system returns to the IP Output Command >
prompt. To configure additional IP channels, repeat steps 1 to 5.
7. When you have set all output IP channels as required, type apply and press Enter at the
IP Output Command > prompt to confirm and apply the configuration data to the system.
The system will display confirmation before returning to the IP Output Command >
prompt, for example:
New IP outputs configuration is now active.
8. At the IP Output Command > prompt, type exit and press Enter to return to the Setup
Menu.
Auto-configure Output IP Channels
This option enables you to have the system auto-increment the output IP channels from a
base multicast IP address and port number. Each program must be assigned a unique IPv4
multicast address. See "Channel Assignments for IP Output" on page 9, and/or check with your
service representative, if necessary.
Note: If you wish to manually configure each IP channel, use the "set" option described above.
1. At the IP Output Command > prompt, type fill and press Enter.
2. At the Enter base multicast IP address [227.0.0.0]: command, either press
Enter to accept the default value in square brackets, or type the appropriate base multicast
IP address and press Enter.
3. At the Enter new multicast port [1234] prompt, either press Enter to accept the
default value in square brackets, or type the appropriate port number for the multicast
streams and press Enter.
52
(Continued on next page)
206-4202
