(Continued from previous page)
12. (RF output only) Complete PIVD100R RF output configuration as follows:
a) If the Command > prompt is on display, type setup and press Enter to access the
Setup Menu.
b) Use the Setup Menu "rf" command, as described on page 50, to configure the RF mode
and the RF channels.
Note: By default, the PIVD100R is configured for QAM-B RF output; thus, when you are
prompted to select the RF mode (initial prompt before RF channel configuration), the
default value shown in square brackets should show the appropriate option for RF output.
c) Connect RF OUT on the PIVD100R rear panel to the RF distribution center combiner,
and balance the RF signal so that the signal level at the TV(s) is between 0 to +7 dBmV.
Caution: For proper system performance, the PIVD100R signal level at the
TV input (ANTENNA IN) must be between 0 to +7 dBmV. Note that additional
equipment (i.e., attenuators) may be required to adjust the signal level.
d) Go to step 14.
13. (IP output only) Complete PIVD100R IP output configuration as follows:
a) If the Command > prompt is on display, type setup and press Enter to access the
Setup Menu.
b) At the Setup Command > prompt, type ipout and press Enter to access the IP
Output Configuration Menu.
c) The IP Output Configuration Menu offers two options for configuring output IP channels:
• To manually configure the output IP channels, use the "set'' command. You will need
to specify a multicast IP address and the multicast port number for each STB/tuner.
• To auto-configure output IP channels from a base multicast IP address and port
number, use the "fill" command. Once you enter the base multicast IP address and
the multicast port number, the system will auto-increment the remaining IP channels.
Refer to "Configure the IP Output" on pages 50 to 53 for further information on the IP
Output Configuration Menu commands. Make sure to use the IP Output Configuration
Menu "apply" command to confirm and apply the configuration data to the system.
d) Once you have completed the output IP channel configuration, at the next IP
Output Command > prompt, type exit and press Enter to return to the Setup Menu
prompt.
e) Connect a CAT5E or better cable between the Feature Port on the PIVD100R rear
panel and the institution's IP distribution network.
f) Continue with step 14.
206-4202
System Setup (Cont.)
(Continued on next page)
