Configuration Options via Command Line (Cont.)

View System Information

1. Log in to the PIVD100R as described on the previous page.
2. At the Command > prompt, type info and press Enter.
The System Information display identifies important information about the PIVD100R,
including the unit serial number, software version, hardware ID (firmware version), Control
Port MAC and IP addresses, and output configuration, for example:
PIVD100R
Pro:Idiom Video Distribution Transcoder System
Copyright (c) 2010-2012 LG Electronics U.S.A, Inc.
Copyright (c) 2010-2012 Zenith Electronics LLC
SN:
Version
HW id:
Ctrl MAC:
Ctrl IP:
STB Type:
Output:
RF config:
RF channels:
Local time:
Note: If the system is configured for IP output, the Output field will show "IP" and RF fields
will not be present.
It is recommended that you record this information for future reference. If you find it
necessary to call customer service or engineering support, please have this information
available.

Monitor the System

This option enables you to view static or dynamic system streaming data.
1. Log in to the PIVD100R as described on the previous page.
2. At the Command > prompt, either:
• Type monitor and press Enter to display the current system data (see examples on the
following page).
• To monitor streaming data in real time, type monitor and the number of seconds before
the data refreshes. Then, press Enter. For example, to refresh the data every second,
type monitor 1 and press Enter.
When you are finished monitoring streaming data, press Enter to stop the system
monitor and return to the Command > prompt.
38
101-12470001
1.5
3-207-79-4
00:0C:63:3B:00:BE
136.166.60.92
DirecTV
RF
Mode 2, QAM-B, RF: 6 MHz, 5.36 MSps
3 4 5 6
Thu Mar 22 14:42:02 CDT 2012
206-4202
