(Continued from previous page)
2. The next step depends on the output mode selected:
• For RF output configuration: In the Start RF Channel field, type the RF start channel
number. The remaining three channels will be automatically assigned per EIA-542 STD
CATV frequency allocation standards.
• For IP output configuration: For each IP channel stream (one per COM 23 STB or two per
ViP 222/ViP 222k STB), type the appropriate multicast IP address and port number in the
IP Address and IP Port fields, respectively.
Note: The IP Output Configuration Fields example above shows IP output configuration
fields for a COM 23 STB, with one program per stream. If the system is configured for
ViP 222/ViP 222k STBs, you will need to specify two programs per stream.
Note: If you would like to have the PIVD100R auto-increment IP channels from a base
multicast IP address, you will need to complete output IP channel configuration from
the command line interface. See "Configure the IP Output" on pages 50 to 53 for further
information.
3. When you have completed the field(s) as required, click on the Set button at the right of the
Start RF Channel field or below the last IP Port field, as applicable.
If you successfully changed output configuration parameters, the system will display
at the bottom of the System Information display. The System Information display will also show
the updated output configuration.
Date and Time Configuration
If your system is configured with ViP 222/ViP 222k STBs, you may want to set the date and
time on the PIVD100R for the purposes of scheduling STB software updates (see "Schedule
an STB Software Update" on page 26 for further information).
By default, the PIVD100R is synchronized with an NTP client and configured for the Central
time zone. If the PIVD100R is connected to the Internet, the NTP client will periodically update
the time setting on the PIVD100R. If the PIVD100R is not connected to the Internet, you also
have the option to disable NTP client synchronization and specify date and time data manually.
1. Click on the down arrow at the right of the Time Zone field in the Time Configuration
section of the System Setup screen, and select the appropriate time zone from the drop-
down list of options.
2. Select the appropriate NTP setting—Enable or Disable—by clicking the radio button at the
left of the appropriate option.
Note: Per your selection, certain of the Time Configuration fields will become inaccessible/
grayed out. If NTP is enabled, Data and Time fields will be grayed out; if NTP is disabled,
the NTP Server field will be grayed out.
206-4202
Configuration Options via GUI (Cont.)
(Continued on next page)
