(Continued from previous page)
Note: If you set a new STB type, you will be prompted to reset the system. If you intend to
modify additional configuration settings during the current session, you may wait until all
changes are complete before you reset the system.
17. If the Setup Command > prompt is on display, type exit and press Enter to return to the
Command > prompt.
18. Set the channel(s) on each of the installed STBs as follows:
a) At the Command > prompt, type stb and press Enter to access the STB Menu.
b) At the Enter STB number > prompt, type the number of the PIVD100R X-Port
connected to the STB for which you wish to set the channel(s). Then, press Enter.
The system will identify the current STB and then display an STB command prompt,
for example:
Current STB: STB-1
STB-1 Command >
c) Use the STB Menu "channel" command, as described on page 42, to set the STB/
tuner channel. If applicable, make sure to set the channel for both STB tuners.
d) Use the STB Menu "stb" command, as described on page 41, to access the STB Menu
for the next STB for which you wish to set the channel(s). Then, use the "channel"
command to set the channel(s) for the (newly) current STB.
Repeat this step to set the channel on each STB/tuner.
19. At the STB Command > prompt, type exit and press Enter to return to the Command >
prompt.
20. (Optional) If you wish to review the system settings at this time, at the Command >
prompt, type info and press Enter to display the system information.
Note: You can also run the "monitor" command, if desired, to review the system settings.
See "Monitor the System" on page 38 for further information.
21. At the Command > prompt, type reset and press Enter to reset the system.
Note: This initiates a reset of the PIVD100R and may also initiate a reset of one or more
STBs, if required. Once the PIVD100R is reset (may take up to 90 seconds), it may then
take up to 10 minutes for the PIVD100R to reestablish communication with the STBs. After
the system reset, the PIVD100R resumes normal operation.
22. Check one or more room receivers to make sure all content is properly mapped and
available.
