Configuration Options via GUI (Cont.)
Output Mode Configuration
In the Output Mode section of the System Setup screen, you can modify the PIVD100R output
configuration (see RF and IP output configuration examples below).
Example: RF Output Configuration Field
Example: IP Output Configuration Fields
Complete output configuration as follows:
1. Select the Output Mode—RF or IP—by clicking the radio button at the left of the appropriate
option.
Note: Depending on the current configuration of the system, when you access the System
Setup screen, either the RF Output Configuration or IP Output Configuration field(s) initially
will be on display below the Output Mode options. If you select a new mode, the system will
display the applicable field(s) per your selection.
30
(Continued on next page)
