Removing the Wireless LAN Module

1. Turn off the computer, and remove the battery (
2. Remove screws - from the memory socket cover
1 6
3. Carefully lift up the memory socket cover
nect it).
4. Remove screws - , and carefully disconnect cables
9 10
5. Lift the Wireless LAN module
a.
1
2 3
4
c.
11
10
9
12
page 2 - 8
).
.
(a fan cable is still attached to the mainboard and you can discon-
7 8
&
11 12
off the computer.
13
b.
6
5
d.
.
8
7
13
Removing the Wireless LAN Module 2 - 15
Disassembly
Figure 8
Wireless LAN
Module Removal
a. Remove the screws.
b. Carefully lift the cover off
the computer.
c. Remove the screws and
disconnect the cables.
d. Remove the WLAN
module.
Antenna Cable
Connection
When re-inserting a
Wireless LAN module,
make sure the antenna
cable connects to the
connector J1 which is
indicated as point 12.
7. Socket Cover
13. WLAN Module
.
• 8 Screws
