Removing the System Memory (RAM)

The computer has one memory socket for 200 pin Small Outline Dual In-line (SO-DIMM) DDRII (DDR2) type memory
modules (see "Memory" on page 1 - 2
detected by the POST routine once you turn on your computer.
1. Turn off the computer, and turn it over and remove the battery
2. Locate the RAM bay cover and remove screws
3. Remove the RAM bay cover
a.
All manuals and user guides at all-guides.com
for details of supported module types). The total memory size is automatically
& .
1 2
.
3
b.
2
1
(page 2 - 5).
Removing the System Memory (RAM) 2 - 11
Disassembly
Figure 7
System Memory
Removal
a. Remove the screws.
b. Remove the cover.
3
3. RAM Bay Cover
• 2 Screws
