Removing The System Memory (Ram) - EUROCOM M375E Service Manual

Disassembly

Removing the System Memory (RAM)

Figure 6
The computer has two memory sockets for 200 pin Small Outline Dual In-line Memory Modules (SO-DIMM) supporting
Removing/
DDR 266/333MHz. The main memory can be expanded up to 2GB. The SO-DIMM modules supported are 128Mb,
Installing a RAM
256Mb, and 512Mb. The total memory size is automatically detected by the POST routine once you turn on your com-
Module
puter.
a. Remove the screws
Memory Upgrade Process
& cover.
1. Turn off the computer, remove the battery
b. Pull the release
latche(s). 2. Locate the RAM bay cover
c.Remove the mod- 3. Remove the bay cover.
4. Gently pull the two release latches (
ule(s).
arrows
5. The RAM module(s)
a.
Contact Warning
Be careful not to touch
the metal pins on the
module's connecting
edge. Even the clean-
est hands have oils
which can attract parti-
cles, and degrade the
module's perfor-
mance.
1. RAM Bay Cover
9. RAM Module
• 5 Screws
2 - 10 Removing the System Memory (RAM)
