Removing the Hard Disk Drive

1. Turn the computer OFF, remove the battery
2. Remove screws - (Figure 2 -
1 3
3. Lift the HDD assembly out of the computer by pulling on the HDD tab
4. Remove screws - (Figure 2 -
6 11
connector board .
14
5. Just reverse the removal procedure to install the new HDD.
a.
1
4
c.
6
13
11
10
12
All manuals and user guides at all-guides.com
(page 2 - 6) and keyboard
4a) which secure the HDD assembly
4c) and separate the HDD from the case
12
b.
2
3
7
The illustrated HDD cable may differ from the
8
14
one in your model depending on the configura-
tion purchased.
9
Be careful not to bend the pins on the hard disk
when removing the cable.
(page 2 - 8).
to the computer.
4
(Figure 2 - 4b).
5
, and disconnect the HDD
13
5
4
HDD Cables
Removing the Hard Disk Drive 2 - 9
Disassembly
Figure 2 - 4
Hard Disk
Removal
Sequence
a. Remove the three
screws and release
the HDD cable.
b. Remove the HDD
assembly.
c. Remove the six
screws and HDD
connector board.
12. HDD
13. HDD case
14. HDD connector
Board
• 9 Screws
