6.
Remove and retain the four screws (two each side) from the bracket.
Screws
Bracket
7.
Secure the new drive to the bracket using the screws removed in the previous step.
8.
Install the drive into the base unit, and secure it using the screws removed in step 3.
9.
Connect the cables to the new drive.
10. Reconnect the SCSI cable to the CD-ROM drive.
Disk Drives
The disk drives in the disk section can be easily replaced as follows.
To replace disk drives:
1.
Open the drive access door on the front of the system.
2.
Flip the drive latches outward to disengage the disk drive. The LED adjacent to the drive turns off.
Refer to the following figure.
9
