Intergraph InterServe 8000 System Reference Manual page 69

Keyboard port, mouse port
The keyboard and mouse ports are PS/2 style, 6-pin ports. They are not interchangeable.
Refer to page 58 for information about the mouse and keyboard functions of the FDC37C932
controller.
J5 Keyboard
Pin Signal
1 KDATA
2 Spare
3 Ground
4 VCC
5 KCLK
6 Spare
Serial Ports
The serial ports (also referred to as RS-232 asynchronous communications ports, or COM
ports) can connect modems, printers, peripherals and other computers to the system. The serial ports
(labeled 1 and 2) are 9-pin, male DB9 connectors. If connecting a serial device with a 25-pin DB25
connector, use a 25-pin to 9-pin adapter cable to mate with the serial port on the system. Only shielded
cables should be used with the serial ports. Refer to page 58 for information about the serial port
functionality of the FDC37C932.
COM1/COM3
Pin Signal
1 COM1 DCD
2 COM1 RD
3 COM1 TD
4 COM1 DTR
5 Ground
6 COM1 DSR
7 COM1 RTS
8 COM1 CTS
9 COM1 RI
J6 Mouse
Pin Signal
1 MDATA
2 Spare
3 Ground
4 VCC
5 MCLK
6 Spare
COM2/COM4
Pin Signal
1 COM2 DCD
2 COM2 RD
3 COM2 TD
4 COM2 DTR
5 Ground
6 COM2 DSR
7 COM2 RTS
8 COM2 CTS
9 COM2 RI
61
