2.
Remove the cables and screws attached to the power distribution board as shown in the following
figures. Six screws (three on each side - two on the bottom, one at the top) secure the power
distribution board to the chassis.
Right side
Left side
Screws
Power Distribution
Board
Bracket
Screws
Power
Distribution
Board
21
