Intergraph InterServe 8000 System Reference Manual page 79

J2: MCBL229A, LCD Cable
Pin Signal
1 Ground
2 No Connect
3 Ground
4 DISPRS
5 DISPRW
6 DISPENB
7 Data 0
J3: MCBL230A, LED Cable
Pin Signal
1 Ground
2 RAID present
3 Channel bad
4 Channel good
5 RPS bad
J14, J16, J18, J19: MCBL145A, Disk Drive Power
Pin Signal Wire Color
1 +12V Yellow
2 Ground Black
CH0 and CH1: MCBL246A, Disk Data Cable
Pin Signal
1-16 Ground
17 Term Power
18 Term Power
19 No Connect
20-34 Ground
35 SCSI Data Bit 12
36 SCSI Data Bit 13
37 SCSI Data Bit 14
38 SCSI Data Bit 15
39 SCSI Data Parity 1
40 SCSI Data Bit 0
41 SCSI Data Bit 1
42 SCSI Data Bit 2
Pin Signal
8 Data 1
9 Data 2
10 Data 3
11 Data 4
12 Data 5
13 Data 6
14 Data 7
Pin Signal
6 RPS green (good)
7 RFAN green (good)
8 RFAN green (good)
9 Ground
10 RAID bell (alarm)
Pin Signal
3 Ground
4 VCC, +5v
Pin Signal
43 SCSI Data Bit 3
44 SCSI Data Bit 4
45 SCSI Data Bit 5
46 SCSI Data Bit 6
47 SCSI Data Bit 7
48 SCSI Data Parity 0
49 SWAP (Ground)
50 Shell OK (Ground)
51 Term Power
52 Term Power
53 No Connect
54 Fault Clock (Ground)
55 Attention
Pin Signal
15 No Connect
16 Menu
17 Escape
18 Down
19 Enter
20 Up
Wire Color
Black
Red
Pin Signal
56 Fault Data
57 Busy
58 Acknowledge
59 Reset
60 Message
61 Select
62 Carrier Detect
63 Request
64 I/O
65 SCSI Data Bit 8
66 SCSI Data Bit 9
67 SCSI Data Bit 10
68 SCSI Data Bit 11
71
