Installing Disk Drives - Intergraph InterServe 800 SL System Setup

12
NOTE The UPS starts automatically when its power cord is connected to the power outlet. Refer to
the UPS documentation for more details.
6. Connect other cables as necessary for printers (parallel port), external SCSI devices
(SCSI port), and modems or UPS communication (serial ports).
7. Install the disk drives as described next.

Installing Disk Drives

The disk section in the front of the system contains either four or eight disk drive mounting
locations. If your system is configured for RAID, it will contain eight drive slots. The slots
are numbered from 1 to 8, starting with the bottom slot. If you are installing less than eight
drives into the system, install the disk drives starting in slot 1, the bottom slot, and fill each
slot in sequence.
The following figure shows the disk section door and door lock on the system.
Disk Section
Door
Door Lock
