Vertical Bay Disk Drives

If Kingston removable disk modules are installed in the system, refer to the Kingston documentation
for disk drive or module replacement instructions.
To replace drives in the vertical bay:
1. Remove the disk drive fan by removing the screw at the top of the vertical bay and disconnecting
the fan power cable from the inline connector.
Screw
Fan
Fan Power Cable
In-line Connector
2. Disconnect the power cable and SCSI cable from the disk drive.
