AC Section (MESAN49)
The following diagram shows the AC wiring for systems with dual 550 Watt power supplies. Systems
with single 539 Watt power supply do not use this wiring.
MSMT332
Side 2
Brown - Line
Green Ground
Blue - Neutral
AC Section
Brown - Line
Green -Ground
Blue - Neutral
Ground Lug
Blue
Brown
69
Terminal
Block
