Intergraph InterServe 8000 System Reference Manual page 18

10
Slot
Guides
3. Slowly pull the drive out of the system. Do not let the drive fall when it clears the rails inside the
internal disk section.
NOTE The drive may continue to spin for a short duration after you remove it from the system.
4. To insert the new drive, extend the latching clips on the disk drive and align the rails on the side of
the drive with the slot guides. The metal casing of the drive faces up.
5. Push the drive between the latching clips until it slides all the way into the slot and firmly engages
the connector.
6. Close the latching clips to lock the drive in the slot.
7. Restart the system and ensure the LED for the new disk drive lights and remains steady green.
8. Label the new drive with the same ADP, CH, and ID numbers used on the replaced drive.
Latches
