Intergraph InterServe 8000 System Reference Manual page 75

J8: MCBL203A, LCD Board System Status
Pin Signal
1 Ground
2 +5V Fuse
3 Ground
4 DISPRS
5 DISPRW
6 DISPENB
7 Data 0
8 Data 1
9 Data 2
10 Data 3
11 Data 4
12 Data 5
J9/J10: MCBL078A, ISM Card Feature Connector
Pin Signal
1 No connect
2 No connect
3 Ground
4 Key
5 PWROFF#
6 No connect
7 LPOK
J12/13/14: MCBL202A, Main Cooling Fans
Pin Signal Color
1 +12V Red
2 Fan Tach Yellow
3 Ground Black
4 Fan Present Black
J16: MCBL210A, Intruder Switch
Pin Signal
1 Intruder Alert (chassis open)
2 Ground
J18, J19: 550 Watt Power Supplies
Refer to "550 Watt Power Supplies (MPWS139)" for the pinout of these connectors. See the table on
page 77.
Pin Signal
13 Data 6
14 Data 7
15 VCC Fuse
16 Menu
17 Escape
18 Down
19 Enter
20 Up
21 System/RAID
22 No Connect
23 Ground
Pin Signal
8 No connect
9 No connect
10 + 3.3V
11 SYS RESET
12 Ground
13 Ground
14 Key
Pin Signal
24 VCC Fuse
25 CHBAD
26 CHGOOD
27 PSBAD
28 PSGREEN
29 FANBAD
30 FANGREEN
31 Ground
32 Bell
33 No Connect
34 No Connect
Pin Signal
15 No connect
16 Ground
17 Intruder Alert
18 No connect
19 Key
20 Ground
67
