40
The following table shows the required and recommended slots for installing Intergraph option boards.
All PCI option boards sold by Intergraph fully comply with the Peripheral Component Interconnect
Specification, 2.1.
Board
Name
InterSite Server Monitor
RAID Controller
FDDI, Single-Attach
FDDI, Dual-Attach
10 Base-T Ethernet
100 Base-T Fast Ethernet
100 Base-VG Fast Ethernet
10/100 Pro100B Ethernet
Token Ring
IKON Plotter Interface
ATM 155 Mbps Network (fiber)
ATM 155 Mbps Network (copper)
SCSI-2 Controller
NOTE
The RAID controller is included in the kits for InterRAID-8e expansion disk array cabinets.
To install option boards:
NOTE
Assign system resources for ISA and non-compliant PCI boards before installation. Refer to th e
section, "Assigning System Resources for Option Boards" in the System Setup.
1.
Remove the right side panel as described in Chapter 1.
2.
Using a quarter-inch nutdriver, remove the screw and blanking plate from an available slot.
3.
Install the option board. Press firmly to ensure the board seats completely into the slot.
4.
Connect the required external cables to the option board.
5.
Secure the board to the chassis using the screw removed in step 2.
6.
Close the base unit.
7.
Restart the system, and note the special information about ISA boards, PnP boards, and the
InterSite Server Monitor card.
For ISA boards, refer to the System Setup document delivered with the system for information
about BIOS parameters that should be set.
For PnP boards, notice when the following message displays: Hit DEL if you want to
run SETUP. Press
System" parameter under PCI/PnP Setup menu. Exit AMIBIOS Setup and restart the system.
Refer to the System Setup document delivered with the system for instructions to use
AMIBIOS Setup.
Sales Level
Part Number
FINF026
(See note)
FINF854
FINF853
FINF846
FINF852
FINF832
FINF920
FINF855
FPLT841
FINFD66
FINFD65
FINF913
to run AMIBIOS Setup, and enable the "Boot to PnP Operating
DELETE
Required
Recommended
Slot
Slot
ISA 4
n/a
PCI 4-8
n/a
Any PCI
PCI 1-3
Any PCI
PCI 1-3
Any PCI
PCI 1-3
Any PCI
PCI 1-3
Any PCI
PCI 1-3
Any PCI
PCI 1-3
Any PCI
PCI 1-3
Any PCI
PCI 1-3
Any PCI
PCI 1-3
Any PCI
PCI 1-3
Any PCI
PCI 1-3
