Cable Connectors
The following table shows the cable connectors from the power supply to various devices in the system.
Connector Device
P1 Power Distribution Board (J21)
P2 Disk Drive Section
P3 Disk Drive Section
P4 Disk Drive Section
P5 Disk Drive Section
P6 CD-ROM Drive
P7 Auxiliary Drive
P8 Auxiliary Drive
P9 Floppy Disk Drive
P10 Power Distribution Board (J1)
P1 Pinout
Pin Signal Wire Color
1 +3.3V Orange
2 +3.3V Orange
3 +3.3V Orange
4 Ground Black
5 Ground Black
6 Ground Black
7 +3.3V Orange
8 +3.3V Orange
9 +5V Red
10 Ground Black
11 +5V Red
12 Ground Black
P2 - P7 Pinout
Pin Signal Wire Color
1 +12V Yellow
2 Return Black
3 Return Black
4 +5V Red
Pin Signal Wire Color
13 +5V Red
14 Ground Black
15 Ground Black
16 +5V Red
17 Ground Black
18 -12V Blue
19 +5V Red
20 -5V Red
21 Ground Black
22 +12V Yellow
23 Ground Black
24 Power Green
